Earthworks Audio TC 20 single room mic

Vivid Sound, No Matter the Volume

The TC20 is an omnidirectional microphone designed for recording louder sources such as drums, percussion, amplified instruments and loud sound effects.

Headroom Perfected

With a whopping SPL rating of 150dB the TC20 has plenty of headroom. And with no proximity effect, you can get it as close as you want to the sound source.

Remarkable Response

With a 9Hz – 20kHz ruler-flat frequency response, and an ultra-fast transient response, the result is a more accurate representation of the original sound.

Control With No Compromise

Its near-perfect omnidirectional polar pattern is uniform across all specified frequencies, letting the microphone capture rich and consistent detail at any position around the capsule.

SPECIFICATIONS:

• Frequency Response: 9Hz to 20kHz ±1/-3dB
• Polar Pattern: Omnidirectional
• Sensitivity: 8mV/Pa (-42dBV/Pa)
• Power Requirements: 24-48V Phantom, 10mA
• Peak Acoustic Input: 150dB SPL
• Output: XLR (pin 2+)
• Output Impedance: 65Ω balanced (between pins 2 & 3)
• Minimum Output Load: 600Ω between pins 2 & 3
• Self Noise: 26dB SPL equivalent (A weighted)
• Dimensions: 165mm x 22mm (6.5 x .860 inches)
• Weight: 160g (.35 lb)

Earthworks Audio Omni Room Mics:
Capture the room. Capture the ambiance. Breathe life into your recordings. Add air into your streams.

TC20: single 20kHz omni room microphone
TC20MP: stereo set 20kHz omni room microphone

QTC30: single 30kHz omni room microphone
QTC30MP: stereo set 30kHz omni room microphone

QTC40: single 40kHz omni room microphone
QTC40MP: stereo set 40kHz omni room microphone

QTC50: single 50kHz omni room microphone
QTC50MP: stereo set 50kHz omni room microphone
