Ehrlund Microphones EHR-D | Price only for current stock

Ehrlund Microphones EHR-D | Price only for current stock

Compacte en robuuste condensatormicrofoon, geoptimaliseerd voor live optredens en luide geluidsbronnen, met een gerichte opname

EHR-D

€825,62excl. 21% BTW This product cheaper?
Click here and become a Gold Client €999,00incl. 21% BTW This product cheaper?
Click here and become a Gold Client

Short term rental

From€ 2.31 / day at 1 week rental

Add to short term rental +

Available in demo room

test in our demo studio!

Reserve time

Questions? Seen a better price?

Call +31 (0) 512 - 340457 or contact us!

Product omschrijving

Ehrlund Microphones EHR-D

Durable excellence, ready for the road

The EHR-D is the smallest, lightest, and most durable of Ehrlunds’ large-diaphragm condenser microphones. Designed with live performance in mind, it is equally well suited for recording percussion, strings, woodwinds, and a wide range of acoustic instruments—where focus, clarity, and reliability matter most.

Its compact size, robust construction, and built-in coarse dirt filter make the EHR-D a dependable companion for life on the road. Built to endure the realities of touring, it delivers the same transparent and natural sound Ehrlund microphones are known for, night after night.

This mic is the drummers delight! Warm, punchy and lots of attack.

With a pickup pattern that is slightly narrower than a traditional cardioid, the EHR-D offers excellent focus. It captures the intended source clearly while reducing unwanted sound from the sides—helping performances stay clean, even in challenging live environments. Bass frequencies are reproduced accurately, even at some distance, and fast transients are handled with ease.

The EHR-D is made for musicians and engineers who need a microphone that works as hard as they do—without ever getting in the way of the music.

BUILT FOR LIVE PERFORMANCE

The smallest and most durable Ehrlund microphone, engineered to deliver reliable, transparent sound night after night on stage.

FOCUSED SOUND, EVEN IN DEMANDING ENVIRONMENTS

A slightly narrower cardioid pattern reduces side bleed and keeps the source clear—perfect for drums, percussion, and acoustic instruments.

PUNCH, CLARITY, AND CONTROL

Fast transients, accurate bass, and high SPL handling make the EHR-D a favourite for dynamic, high-energy performances.

Characteristics & features

Large-diaphragm condenser microphone
Patented triangular membrane design
Internal amplification and power circuitry
Optimized for live environments and instrument recording
Transparent and natural sound
Excellent low-noise performance
Phase- and frequency-linear internal amplifiers
Compact size and lightweight construction
Built-in coarse dirt filter
Durable design, made to withstand life on tour
Slightly narrower cardioid pattern for reduced side bleed
Accurate bass reproduction, even at moderate distances
Natural reproduction of fast transients
Handles sound pressure levels up to 137 dB SPL at <1% THD
Negligible sound coloration, true to the original source
Frequency range from infrasonic bass to ultrasonic treble
Low energy consumption, approx. 2.0 mA
Designed for flat EQ—no pre-filtering required
Every Ehrlund microphone is individually stereo-matched within its model
Unaffected by load impedance

Technical specifications

Type: Condenser microphone
Membrane type: Triangular membrane combining characteristics of both large and small diaphragms
Pickup pattern: Cardioid
Frequency range: 7 Hz – 87,000 Hz
Sensitivity at 1 kHz: −42 dBV/Pa (8 mV/Pa)
Impedance: Unaffected by load impedance
Equivalent noise level: < 9 dBA
Signal-to-noise ratio: 85 dBA
Dynamic range: 128 dB
Max SPL (peak):
– 132 dB SPL @ 0.5% THD
– 137 dB SPL @ 1% THD
– 155 dB SPL (clip)
Power supply: 48 V phantom power
Current consumption: 2.0 mA
Connector: 3-pin XLR
Materials: Aircraft-grade aluminium body, hardened nickel-plated stainless-steel grille
Finish: Glass bead blasted
Dimensions: Ø53 mm × 72 mm
Weight: 170 g
