Type Alpha 50 Evo Monitoring
Frequency response
(+/- 3dB) 45Hz - 22kHz
Maximum SPL
101dB SPL (peak @ 1m)
Inputs Connectors
TRS: symmetrical 10kOhms
XLR: symmetrical 10kOhms
RCA: asymmetrical 10kOhms with compensated sensitivity
Medium and low frequency amplifier
35W
High frequency amplifier
25W
Automatic stand-by mode
After around 15 minutes of no use By signal detection >6mV
Power supply
100 - 240V~ (T2AL fuse/250V)
Connection
IEC socket and detachable power cable
Sensitivity
Adjustable, 0 or +6dB Level midrange/bass (0 - 250Hz) Adjustable, +/-6dB Treble level (4.5 - 35kHz) Adjustable, +/-3dB
Power on/off
On/off switch on the rear panel
Stand-by consumption
<0.5W
Views and controls
On and off LED - Stand-by LED
Woofer
5" (13cm) Slatefiber cone
Tweeter 25mm
(1") with aluminium inverted dome
Construction
0.6" (15mm) MDF
Finish
Black vinyl and paint
Dimensions
with 4 rubber feet (HxWxD) 12.2x9x9.41" (310x228x239mm)
Weight
13.1lbs (5.95kg)
