Microtech Gefell M 940-Stereo ORTF Satin Nickel

Microtech Gefell M 940-Stereo ORTF Satin Nickle

Matched pair of M 940 with 2 microphone holders MH 93.1 and a double mount TD 93, in wooden case.

The M 940 studio condenser microphone combine modern large diaphragm capsule technology with the latest in semiconductor circuit topology. They are specifically designed to meet the needs of professional and semi-professional users who demand the highest performance. The microphones are ideally suited for universal miking applications in broadcast and sound studios. They are also attractive for project studios. Applications include vocalists, announcers, dialog pickup and as spot microphones for recording guitars, keyboard, percussion, wind and string instruments.

The electronic impedance converter uses a perfected circuit topology. This design reduces the noise floor to an extremely low level while also raising the maximum output capability. As a result, these microphones have a clean, distortion free sound over anextremely wide dynamic range. RFI susceptibility is very low.

Technical data

Polar pattern cardioid

Acoustic operating principle pressure gradient transducer

Frequency range 20 Hz to 20.000 Hz

Sensitivity at 1 kHz 23 mV/ Pa

Output impedance 100 Ohm

Noise level CCIR 468-412 dB

DIN EN 60268 -46 dB-A

Signal-to-noise ratioCCIR weighted 82 dB

A-weighted 88 dB

SPL for THD 0,5 % 141 dB

Max. output levelR = 1 kOhm 17 dBu

R = 10 kOhm 18 dBu

Dynamic range 135 dB

Current consumption 3,6 mA

Output connecto rXLR3M

Weight 210 g

Length 118 mm

Diameter 45 mm

Surface satin nickel, dark bronze
